The 2000W 12V Pure Sine Wave Inverter with Power Saving Mode (New Edition) is engineered to meet the rigorous demands of overlanding and off-roading enthusiasts. This inverter efficiently converts 12V DC battery power into clean, reliable 120V AC electricity, ensuring your essential devices and appliances operate seamlessly, even in remote locations.

Key Features:

• Continuous Output Power: 2000W
• Surge Rating: 4000W (1 second)
• Output Voltage: 120V AC ±10%
• Output Frequency: Configurable to 50Hz or 60Hz
• Output Waveform: Pure Sine Wave
• Total Harmonic Distortion (THD): < 3% for linear loads; < 5% for non-linear loads
• Inverter Efficiency: > 92%
• Full Load Efficiency: > 89%
• Power Consumption: < 10W
• ECO Power Consumption: < 5W
• Communication: RS485 interface for monitoring and control
• Cooling: Thermally controlled fans for optimal performance

Mechanical Specifications:

• Dimensions (L x W x H): 15.8 x 9.8 x 3.8 in (401 x 249 x 96 mm)
• Weight: 10.4 lbs (4.7 kg)
• Operating Temperature Range: -4°F to 104°F (-20°C to 40°C)
• Storage Temperature Range: -40°F to 158°F (-40°C to 70°C)
• Humidity: Up to 93%, non-condensing

Input Specifications:

• Rated Battery Input Voltage: 12V DC
• Battery Input Voltage Range: 11V DC to 16.5V DC
• Maximum Continuous Battery Input Current: 166.6A
• Battery Overvoltage Shutdown: 16.5V DC
• Battery Low Voltage Alarm: 10.5V DC
• Battery Low Voltage Shutdown: 10V DC

Output Specifications:

• Continuous Output Current: 8.3A AC
• AC Terminals: 2 x AC sockets plus terminal block

Accessories Included:

• Wired Remote Control:
  • Overall Dimensions: 2.8 x 4.3 x 1.3 in (70 x 110 x 31.8 mm)
  • Cable Length: 16.4 ft

Warranty:

• Material and Workmanship Warranty: 1 Year

Equip your vehicle with the 2000W 12V Pure Sine Wave Inverter with Power Saving Mode to ensure consistent and clean power supply during your off-road and overland journeys. Its robust design and high efficiency make it an essential component for powering your adventures.
